Protecting Human Health Without the Use of
Harmful Chemicals or Materials
AquiSense are passionate about developing solutions that solve real-world problems in water, air, and surface disinfection applications. They do it for people at home, in hospitals, airplanes, and even astronauts. Eventually our products will provide reliable, lower cost water to millions in remote communities. AquiSense works with leading UV-C LED manufacturers to evaluate their devices. Using a combination of patented technology and in-depth know-how, we integrate only the best LED devices into our products.




Surface Disinfection
Disinfecting surfaces becomes simple with the PearlSurface.
The 3 x 3 inch square PearlSurface modules can be operated individually or assembled into large arrays to fit any application. Each module can be outfitted with a single wavelength and assembled in such a way as to provide multi-wavelength coverage. The PearlSurface eliminates hotspots by homogenizing the LED’s light and giving a uniformed intensity distribution to treated surfaces.
Wavelengths between 265nm and 285nm are typically used for disinfection, but other wavelengths are available as well. UV-C LEDs allow nearly any wavelength(s) to be selected so highly targeted pathogen reduction is possible.
As with all Pearl products, the PearlSurface is small, rugged, and lightweight making it easy to mount and ideal for portable disinfection.

PearlSurface for curing uses UV-C wavelengths between 265 and 310nm. This spectrum allows for specialized curing on
the top level sealing the surface of the product.
This application also provides the option of reduced working distance as the UV-C LEDs can be placed at a closer distance than mercury lamps without adding heat to the surface and prevents cracking or drying. Heat is only produced on the back of the LED chip where a heatsink and fans can cool the device.
These devices are modular, hot-swappable, and power customizable allowing power to be easily targeted for the actual width of each project. With dimmable optical power output and PLC remote On/Off capability, PearlSurface can be arranged in a number of configurations and integrated into existing production lines.
The PearlSurface eliminates hotspots by homogenizing the LED’s light
and giving a uniform dose to treated surfaces.
UV-C Curing
